Air compressors are one kind of common power equipment. In simple terms,   it is a device that compresses air to generate potential energy. Therefore,   it has a wide range of applications. The common applications mainly include   the following industries:

Mine

Air for ventilation,   drilling large holes, removing water with compressed air, filtering fines,   pneumatic hoist, driving rock drilling rigs, pneumatic drilling, blowing   holes, piling machines, rock drilling machines, etc.

Factory

Air jet cleaning, driven   tools (steam hammers, concrete shakers, drills, grinders, cranes, paving   breakers, riveting guns, descaling, pipe reels, wrenches), sandblasting,   metallization, painting, water spray systems

Sheet metal

Stirring solutions,   transporting chips, jet cleaning, driving packaging presses, driving platen   chuck clutches and positioners, air tools, finishing hammers, air picks,   drills, grinders, hoists and lifters, combination tools, riveters, Sand   blasting, lubricant spraying, paint spraying, container leak detection

Forging

Blown   oxide surface, furnace door air curtain, hoist and lift, drive bending and   straightening machine, drive clutch brake and clamping device, drive forging   hammer, fuel burner

Casting

Hot   metal truck positioning, cleaning equipment, conveying sand, driving   pneumatic tools, sanding machines, grinding machines, hoists and lifts, air   picks, tamping machines, steel brushes, sandblasting, sand screening, mud   blasting cores

Quarry

Lifting   and handling materials, rock drilling rigs, gas supply, drilling and blasting   machines, rock drilling machines, hand drills, water pumps

Rubber industry

Cleaning   of moulds and machinery, air lift, demolding, mould opening, pneumatic   control, spraying

Textile industry

Mixing   liquids, air lifts, wetting, running accumulators, spraying liquids, spraying   systems, infusions

Chemical fiber

Gas for instrumentation, gas for silk   suction gun and power source for printing and dyeing, etc.

Cement

Storage ventilation,   cement slurry mixing, cement bag cleaning and sealing, raw material mixing,   dump truck, cleaning equipment, clinker cooling, cement and coal conveying,   cement kiln cleaning, vehicle and ship loading and unloading, lifting and   hoisting, pneumatic control

Chemical

Aeration   and agitation, separation tower gas, cleaning equipment, combustion gas,   conveying, lifting liquid, spraying, cleaning pipeline, pneumatic control,   process gas, conveying liquid

Thermal power

Instrumentation,   desulfurization and denitrification, blowing and cleaning pipes, bag dust   removal, blowing off soot, cleaning boiler and condenser pipes, jet cleaning,   transferring pulverized coal, removing sewage, pneumatic control, auxiliary   equipment control, coal-fired transportation, industrial Water treatment   equipment, etc.

Hydropower

Engine control, lock   maintenance, drive controller, drive lubrication pump, drive lock, start   control, cleaning garbage net

Beverage

Bottle   washing machines, canning machines, interior spraying of wine barrels, gas   for the food industry

Food

Stirring   liquid, gas (oxygen) for fermentation tank, cleaning equipment with nozzle,   cleaning container with nozzle, material conveying, material filling,   fermentation, food dehydration, filtration

Glass   industry

Blowing   bottles and glassware, blowing lamps and electron tubes, supporting   combustion of glass liquid, transferring raw materials, glass etching,   clearing and drilling, conveying glass, pneumatic control, vacuum hanging   plate, purging of residual material in the oil gun, cooling and cooling of   the gun body, Bag dust removal and filter cartridge backflushing.

Steel

Stirring   solution, gas for deoxidation, gas for high-level converter, positioning of   charging car, drilling of sediment chamber, unloading bag, cleaning of   open-hearth furnace flue, driving clutch and brake, driving furnace door,   driving charging and conveying device, driving lubrication system, Drives   pneumatic tools, picks, grinders, hoists and lifts, sandblasting, blast   furnace blasting, vacuum degassing

Wood and   furniture

Jet   cleaning, air hoisting, impregnated wood, bending and straightening, clamping   and clamping, pneumatic tools, engraving tools, drilling rigs, polishing   machines, sanding machines, sandblasting, painting, water spraying

Refinery

Combustion   gases, draining and cleaning oil circuits, hoisting and hoisting, drive   control systems, catalyst recirculation, sandblasting, painting

Paper

Air   cleaning equipment, hoists and lifts, pool anti-icing, roll feeding, pressed   paper products, drive clutches, drive paper breakers, feed through machines,   pneumatic controls, head case pressurization, head case removal, waste paper   removal , vacuum drying

Pharmaceutical

Stirring   liquids, gas (oxygen) for fermentation of antibiotics, conveying raw   materials, mixing and stirring raw materials, driving centrifuges, pneumatic   control, jet pulverization, spray drying, transferring liquids, vacuum   drying, vaporization and instrument gas

Plastic

Cleaning   of jet equipment, casting blanks, inflation of air objects for molding,   inflation into tubes during extrusion, vacuum or pressure molding, cylinder   operation

Printing

Stir the   solution, pack paper, lift

Injection mold

Air   assisted injection molding

Metallurgical

Metal   smelting, sintering, cold rolling, hot rolling, bundling and packaging of   wire rods and sheets, production lines for continuous casting and rolling,   etc.

3D printing

Base room waste heat, particle, powder   purge

Military

Packaging of explosives, automatic control   devices of torpedoes, automation equipment of ships, equipment purging,   instrument gas, power execution and other operations.

Tobacco

It is also used in power execution   equipment such as wire injection machines, cigarette rolls, splicing and   packaging, as well as instruments and equipment cleaning.

Medical chamber

Supply and exhaust (oxygen) systems for air   pressurized chambers and pure oxygen pressurized chambers

Automobile

Spray Washing Machines, Drive Assembly   Tools, Lifting, Pneumatic Controls, Tire Inflation, Forging Shops, Foundry   Shops, Sheet Metal Shops

Aircraft

Blasting machines, stripping, driving   assembly tools, drilling rigs, steam hammers, hoists, combination tools,   reamers, riveting guns, screwdrivers, forging hammers, metal forming presses,   sandblasting, painting

Aerospace

The rocket is purged with high-pressure   nitrogen, and the oil-free high-pressure chamber is purged. In the aerospace   industry, in addition to being able to withstand irradiation and high   temperature, pneumatic devices can also withstand large acceleration speeds,   so they have been widely used in the control of modern aircraft, rockets and   missiles.

N.m3/min

Mpa

KW

HP

DB

Length*Width*Height

KG

JMWD-45APM

JMWD-45WPM

4.40~7.60

0.7

45

60

69±2

2200*1400*2000(A)

2300*1500*1720(W)

DN50

2650

2700

4.40~7.60

0.8

3.90~6.90

1.0

JMWD-55APM

JMWD-55WPM

5.60~9.60

0.7

55

75

69±2

2200*1400*2000(A)

2300*1500*1720(W)

DN50

2850

2900

5.10~8.90

0.8

4.50~7.90

1.0

JMWD-75APM

JMWD-75WPM

7.30~12.50

0.7

75

100

70±2

2200*1400*2000(A)

2300*1500*1720(W)

DN50

2950

2900

7.30~12.50

0.8

6.50~11.20

1.0

JMWD-90APM

JMWD-90WPM

9.40~16.00

0.7

90

120

71±2

2200*1400*2000(A)

2300*1500*1720(W)

DN50

3000

2950

8.50~14.50

0.8

7.50~12.90

1.0

JMWD-110APM

JMWD-110WPM

11.50~19.50

0.7

110

150

71±2

3000*1990*2180(A)

2700*1800*1830(W)

DN65

3500

3550

11.50~19.50

0.8

9.50~16.20

1.0

JMWD-132APM

JMWD-132WPM

13.60~23.00

0.7

132

180

73±2

3000*1990*2180(A)

2700*1800*1830(W)

DN65

3550

3600

13.60~23.00

0.8

11.80~20.00

1.0

JMWD-160APM

JMWD-160WPM

15.40~26.00

0.7

160

215

73±2

3000*1990*2180(A)
  2700*1800*1830(W)

DN65

3650

3700

15.40~26.00

0.8

13.90~23.50

1.0

JMWD-185APM

JMWD-185WPM

17.80~30.00

0.7

185

250

74±2

3000*1990*2180(A)

2700*1800*1830(W)

DN65

4100

4200

17.80~30.00

0.8

15.40~26.00

1.0

JMWD-200APM

JMWD-220WPM

20.00~33.60

0.7

200

270

74±2

3100*2100*2065(W)

DN100

4500

20.00~33.60

0.8

17.30~29.20

1.0

JMWD-250APM

JMWD-250WPM

27.40~46.00

0.7

250

350

74±2

3100*2100*2065(W)

DN100

5200

27.40~42.00

0.8

22.40~37.60

1.0
