MAM880C Variable frequency all-in-one display

MAM880C Variable frequency all-in-one display

Performance characteristics:

It is applicable to variable frequency screw air compressor, it is all-in-one design.

MAM880C Variable frequency all-in-one display

Technical parameters:

Model: MAM-880c

Size: 250 * 150 * 52mm

Hole size: 239 * 139mm

Display size: 33 * 66mm

Product material: plastic

Working power supply: 16-28v / 10W

Switching value: 3

Relay output: 5

Pressure 4-20mA input: 1

Temperature (PT100 / PT1000): 1

Current: 3

Phase sequence: 1

Plug or screw terminal: screw

Frequency conversion: support

Support RS485 communication: Yes

Pressure transmitter or pressure switch: optional

Voltage detection: optional

Manual download:

MAM880C En.pdf

Schematic download:

MAM880C Schematic Diagram.pdf
