JOY MACHINERY (SHANGHAI) CO.,LTD.
PRECISION FILTER MAIN PIPE FILTER
International compressed air quality class: Contaminants and purity classes (ISO8573-1)
Quality Class | Max Particle Radius | Water | Oil |
Particle Radius (μm) | Min Pressure Dew Point (℃) | Max Oil Content mg/m3(ppm) | |
1 | 0.1 | -70 | 0.01(0.008) |
2 | 1 | -40 | 0.1(0.08) |
3 | 5 | -20 | 1(0.83) |
4 | 15 | 3 | 5(4.2) |
5 | 40 | 7 | 25(21) |
6 | / | 10 | / |
Filter performance parameters
Filter Class | Filter Precision | Residual Oil Content | Initial Pressure Drop(Mpa) | |
μm | ppm | Dry | Wet | |
9 | 3 | 5 | 0.007 | 0.011 |
7 | 1 | 1 | 0.007 | 0.014 |
5 | 0.01 | 0.01 | 0.01 | 0.021 |
3 | 0.01 | 0.003 | 0.01 | 0.042 |
1 | 0.01 | 0.001 | 0.01 | Not applicable |
 |  | Working Conditions: 1. Flow(M3/min)：1.2-600 2. Pressure range (Mpa): 0-1.25 3. Temperature Range (℃): up to 66 |
Characteristic
● The piston type filter core is sealed with the casing to prevent the unfiltered gas from bypassing the filter.
● Corrosive resistant stainless steel filter core, in order to enhance the performance, lower air resistant, to strengthen it with slit welding
● New "matrix mixed fiber" medium, big effective surface area, improving filtration rate, ensuring high efficiency; minimizing pressure drop with big open area
● Closed film sleeve, oil and acid resistance; prevent coalescence of liquid re-mixed air
● Chemically resistant end caps bonded to the medium with special binders
● No silicone resin
● Withstand the high temperature up to 66℃
JOY MACHINERY (SHANGHAI) CO.,LTD.
PRECISION FILTER MAIN PIPE FILTER PARAMETERS
Model | Flow Capacity | Connection Caliber | Dimension (mm) | Filter | Weight | |
N.m3/min | CFM | L*W, mm | Quantity | KG | ||
JMAF-7-001 | 1.5 | 53 | ZG1” | 300*105 | 1 | 1.5 |
JMAF-7-002 | 2.6 | 92 | ZG1” | 300*105 | 1 | 1.7 |
JMAF-7-003 | 3.8 | 134 | ZG1 1/2” | 370*125 | 1 | 2.5 |
JMAF-7-006 | 6.8 | 240 | ZG1 1/2” | 500*125 | 1 | 3.0 |
JMAF-7-008 | 8.5 | 300 | ZG2” | 600*140 | 1 | 4.5 |
JMAF-7-010 | 11.5 | 405 | ZG2” | 600*140 | 1 | 5.0 |
JMAF-7-013 | 13.5 | 477 | ZG2” | 800*135 | 1 | 7.5 |
JMAF-7-015 | 17 | 600 | DN65 | 1000*380 | 1 | 65 |
JMAF-7-020 | 23 | 812 | DN80 | 1100*380 | 1 | 70 |
JMAF-7-025 | 27 | 953 | DN80 | 1100*420 | 1 | 85 |
JMAF-7-030 | 34 | 1200 | DN100 | 1100*440 | 2 | 90 |
JMAF-7-040 | 45 | 1590 | DN100 | 1185*440 | 2 | 100 |
JMAF-7-050 | 55 | 1942 | DN100 | 1185*440 | 3 | 105 |
JMAF-7-060 | 65 | 2295 | DN125 | 1335*517 | 3 | 120 |
JMAF-7-080 | 87 | 3071 | DN150 | 1335*580 | 4 | 160 |
JMAF-7-100 | 110 | 3883 | DN150 | 1410*600 | 5 | 200 |
JMAF-7-150 | 165 | 5825 | DN200 | 1540*600 | 8 | 250 |
JMAF-7-200 | 210 | 7413 | DN200 | 1568*750 | 10 | 300 |
JMAF-7-250 | 260 | 9178 | DN250 | 1700*850 | 12 | 320 |
JMAF-7-300 | 320 | 11296 | DN250 | 1700*850 | 14 | 350 |
JMAF-7-350 | 360 | 12708 | DN300 | 1750*950 | 16 | 420 |
JMAF-7-400 | 410 | 14473 | DN300 | 1750*950 | 19 | 435 |
