What are the main differences between screw air compressors and piston air compressors?

What is the difference between screw air compressors and piston air compressors? To explain clearly, it is necessary to analyse the basic principles, advantages and disadvantages of screw air compressors and piston air compressors in detail. By understanding their structure, working principles, and comparing their advantages and disadvantages, we can clearly understand the differences between screw air compressors and piston air compressors.

Working principle and advantages and disadvantages of screw air compressors:

Working principle of screw air compressor:

A screw air compressor is an air compressor that pressurizes gas through the mechanical movement of the master and slave screws. Its working principle can be summarized as the following main steps:

1. Inhalation: The intake valve of the screw air compressor is opened, and the air pressure in the screw compression chamber is lower than atmospheric pressure. The air is filtered out of impurities and pollutants by the filtering device and then sucked into the compression chamber.

2. Compression: When two screws rotate, the air is limited by the gap between the shell of the compression chamber and the rotating screw. The interaction between the gear and rack will cause the gas between the rotating screws to be compressed, and the air pressure and temperature inside the cavity will gradually increase.

3. Exhaust: After the gas is compressed to meet the pressure standard, it will be discharged through the outlet valve. During the exhaust process, the air is cooled by a cooler and separated from the sediment by a separator.

4. Circulation: During the operation of a screw air compressor, gas will circulate and flow in the compression chamber, and after being cooled by a gas cooler, it will enter the screw compression chamber again for compression.

Advantages of screw air compressors:

1. Higher efficiency: Screw compressors have higher efficiency than piston compressors and can operate continuously at full load.

2. Low noise and vibration: Screw compressors operate quieter and produce less vibration than piston compressors.

3. High gas production: The screw type air compressor has a larger size than the piston type air compressor and can be used for continuous and heavy-duty applications, with a gas production capacity of up to 50m ³/ Min.

4. The screw is not easily worn: due to the lack of direct contact between the female and male rotors, its service life is longer.

Disadvantages of screw air compressors:

1. High cost: Screw compressors are more expensive than piston compressors.

2. Not suitable for intermittent use: Screw type air compressors are not suitable for intermittent use and should operate continuously.

3. Larger size: The screw type air compressor has a larger size and may not be suitable for use in small spaces.

4. Complex design: The design of screw compressors is more complex than piston compressors, making them more difficult to repair and maintain.

Working principle and advantages and disadvantages of piston air compressor:

Working principle of piston air compressor:

It uses a crank connecting rod mechanism to transform the rotational motion of the prime mover into a linear reciprocating motion of the piston, and uses the automatic opening and closing of the inlet and outlet valves to suck in, compress, and exhaust gas. Due to the outdated method used, the gas contains a large amount of oil, which is not suitable for industries with high gas accuracy requirements. Additionally, there are also problems such as high noise, gas pulse, and easy damage to the main engine.

Advantages of piston air compressors:

1. Low cost: piston compressors are usually cheaper than screw compressors.

2. Suitable for intermittent use: The piston type air compressor is suitable for intermittent use and can be turned off when not in use.

3. Easy to maintain: The piston air compressor has a simple design and is easy to maintain.

4. Compact size: The piston air compressor has multiple sizes to choose from, suitable for use in narrow spaces.

5. High pressure output: The piston type air compressor can generate high pressure output, making it suitable for a wide range of applications.

Disadvantages of piston air compressors:

1. Noise operation: Due to the reciprocating motion of the piston, the piston type air compressor produces more noise than the screw type air compressor.

2. High vibration: The piston type air compressor produces greater vibration than the screw type air compressor, which can cause wear and tear on the air compressor and other equipment.

3. Limited capacity: The capacity of piston type air compressors is limited and not suitable for continuous or heavy-duty use.

4. Easy to wear and tear: The uneven reciprocating motion of the piston rod causes rapid wear and is often prone to damage

In summary, both piston air compressors and screw air compressors have their own advantages and disadvantages, and the choice between them depends on the specific requirements of the application.
