Precautions for daily use of screw air compressor

This article mainly introduces the precautions for daily use of the lower screw air compressor and the preparation before the maintenance of the air compressor.

1、 To recognize the importance of lubricating oil, it is necessary to change the oil regularly

The special oil for air compressor is semi synthetic oil, and its service life is generally 3000-4000h. Pay attention to the oil quality and the oil level during operation. The oil level indication during operation must be in the green area. During operation, the oil temperature should be controlled to avoid water in the oil tank. Regularly replace the lubricating oil. Changing the lubricating oil will not only drain the oil in the oil tank, if so, 15% of the oil will not be drained, but also remove the oil at the reversing valve, oil cut-off valve, oil cooler plug, etc. and drain the remaining oil in the oil pipeline to ensure that the oil is drained to ensure that the newly added oil is clean.

2、 The cabinet is well ventilated

3、 Regularly check running, emitting, dripping and leaking

Compressed air leakage is typical in 10% - 25% of most systems. Compressed air leakage requires the unit to be constantly loaded to meet the pressure requirements, which will consume more electric energy. Oil system leakage will accelerate the loss of oil, and the cost of replenishing oil will increase. Therefore, it is necessary to regularly check the leakage of the compressed air pipe network and check whether there is leakage in the oil circuit. To reduce production costs.

4、 Add lubricating grease to the motor regularly

5、 Measure the current and voltage regularly.

Unbalance of 1% of three-phase voltage will cause a phase current exceeding 10%; The unbalanced three-phase voltage of 3.5% will increase the motor temperature rise by 25 ℃. Therefore, the current and voltage should be tested regularly. The motor must not be connected reversely when wiring, otherwise the oil injection screw will reverse, resulting in bearing damage and screw seizure.

6、 The surface of the motor shall be cleaned, and dust and insect debris shall be removed from the motor fan blade cover and motor radiator.

7、 The air compressor equipment shall be maintained for 4000h and 8000h regularly.

8、 Importance of Preventive Maintenance for Oil Injection Compressor

Air filter, filtering accuracy ≤ 20-30 μ M The blockage of air filter will cause the increase of compression ratio and temperature at the same time and reduce the performance, and the intake pipe with steel wire inside will be compressed by negative pressure. The filtering accuracy of the air filter is not enough, and the screw air compressor will cause dust to enter the oil circulation system, contaminate the lubricating oil, block the oil filter and oil gas separator, and cause greater losses.

Improper maintenance of air inlet valve and air inlet valve will lead to unit performance degradation, energy waste and oil entering the air.

Filtering accuracy of oil-gas separator ≤ 0.1 μ m. If the residual oil content is ≤ 3PPM, the failure of the oil gas separator of the screw air compressor will cause stronger oil flow due to blockage, or more oil residues will enter the air pipe network of the end user due to poor oil gas separation.

Minimum pressure valve, the failure of which will prevent oil from entering and cause low oil pressure, thus causing failure of lubricating oil sealing device between rotors. In addition, it may cause the compressed air to flow backward from the air pipe.

Temperature control valve: when the temperature of lubricating oil is lower than 60 ℃, the screw type air compressor oil temperature valve acts, so that the oil does not pass through the oil cooler and directly passes through the oil filter to the machine head. In fact, this situation is almost impossible. The failure of the valve may cause the oil cooler to be bypassed, and then the oil temperature will rise, the oil system will fail, and the high temperature trip will occur.

Oil filter, filtering accuracy ≤ 10-12 μ m. Failure of the oil filter may lead to lack of oil and high temperature of the machine head, or it may enter the main engine without filtering.

The failure of the oil shutoff valve will prevent oil from being injected into the rotor, which will lead to the seizure or failure of the rotor of the screw air compressor.

9、 Precautions during installation of air compressor

Condensed water pipes shall be separately connected to drainage ditches.

The cooling water inlet pipe shall be equipped with a filter

Attention shall be paid to the quality, flow, pressure and temperature of cooling water.

10、 Case analysis, common fault judgment

Abnormal unit loading and unloading; Abnormal startup and shutdown; The abnormal exhaust pressure is usually the fault of the control system.

Oil leakage and shortage of the unit; The temperature of the oil and gas discharged from the machine head is too high or too low, which is usually a problem of the oil circuit system.

The exhaust pressure of the unit is abnormal or the oil and screw air compressor water in the exhaust are overweight; Unbalance of internal and external pressure is usually a problem of gas circuit system.

Abnormal noise, excessive vibration, excessive running current, etc. during unit operation are faults of main and motor systems.
